Product Description:

Our factory can produce the stud and unstudded marine anchor chain of level Ⅰ, Ⅱ and Ⅲ with the Φ12.5mm-Φ66mm diameter, Φ6mm-Φ66 chain, Φ12.5mm-Φ66mm swivel, Φ13mm-Φ66mm joint shackle, Φ13mm-Φ65mm end shackle, Φ13mm-Φ70mm nonstandard anchor chain made of various material and specification, stainless chain, enlarged link, ring link, triangle link and ring hook, rigging, etc...


Product Detail

无档锚链 链环尺寸(6*36D) 破断负荷 重量

OPEN LINK ANCHOR CHAIN/STUDLESS ANCHOR CHAIN, LINK SIZE(6*3.6D), BREAKING LOAD WEIGHT

直径

DIAM

ETER

链环尺寸

CHAIN LINK SIZE



1级无档锚链

BM1

U1 OPEN LINK CHAIN

2级无档锚链

BM2

U2 OPEN LINK CHAIN

3级无档锚链

BM3

U3 OPEN LINK CHAIN

节重

APPROX.

WEIGHT

外长L

OUTSIDE

LENGTH

外宽B

OUTSIDE

WIDTH

破断拉力

BREAKING  LOAD

破断拉力

BREAKING  LOAD

破断拉力

BREAKING  LOAD

27.5M

MM

MM

MM

KN

KN

KN

KG

12.5

75

45

57.81

82.6

112.80

85.41

14

84

50.4

69.93

101.90

141.51

106.55

16

96

57.6

94.72

132.30

184.83

139.43

17.5

105

63

113.31

157.78

221.10

178.35

19

114

68.4

133.57

187.20

260.64

217.68

20.5

123

73.8

155.49

217.27

303.42

229.14

22

132

79.2

179.08

250.90

349.4

264.49

24

144

86.4

213.25

298.90

415.8

341.82

26

156

93.6

250.12

350.80

488.00

369.94

28

168

100.8

290.08

406.70

566.00

427.04

30

180

108

333.00

467.50

649.80

490.98

32

192

115.2

378.88

531.20

739.30

559.65

34

204

122.4

427.72

599.80

834.60

671.52

36

216

129.6

479.52

672.30

935.70

707.85

38

228

136.8

534.28

748.70

1042.50

788.98

40

240

144

592.00

829.10

1155.20

869.36

42

252

151.2

652.68

915.30

1273.60

959.30

44

264

158.4

716.32

999.60

1398.00

1111.25

46

276

165.6

782.92

1097.60

1527.80

1152.07

48

288

172.8

852.48

1195.60

1663.50

1256.26

50

300

180

926.09

1293.60

1805.00

1360.41

52

312

187.2

1000.48

1395.26

1952.28

1485.61

54

324

194.4

1078.92

1504.66

2105.36

1648.08

56

336

201.6

1160.32

1618.18

2264.20

1715.97

58

348

208.8

1244.68

1735.82

2428.80

1844.50

60

360

216

1332.00

1857.60

2599.20

1973.29

62

372

223.2

1422.28

1983.50

2775.36

2101.56

64

384

230.4

1515.52

2113.54

2957.32

2298.47

66

396

237.6

1611.72

2247.70

3145.04

2398.10

68

408

244.8

1710.88

2385.98

3338.52

2522.88

70

420

252

1813.00

2528.40

3537.80

2697.65
